Customized Mini Tungsten Carbide Nozzle Power Tool Parts OEM Service Acceptable

Ask Lasest Price
Brand Name :	ZONCO
Model Number :	Customized
Certification :	ISO9001:2015
Price :	Negotiable
Payment Terms :	L/C, T/T,
Supply Ability :	1000000 piece/pieces per month
Delivery Time :	30-35 working days

Add to Cart

Product Details
Company Profile

Customized Mini Tungsten Carbide Nozzle Power Tool Parts OEM Service Acceptable

Customized Tungsten Carbide Mini Nozzles

Quick details

Type: Power Tool Parts	Model Type:Customized	Trade Term: CIF,EXW,FOB
Cobalt Content (%): 8%, 10%, 6%	Virgin material:100%	Surface: Ground or Blanks
Trial Order: Acceptable	OEM Service: Acceptable	Delivery Time: Shipped in 10 days after payment

Product Description

The cemented carbide nozzles will be used mainly to PDC drill bits and roller core flushing, drill bits for cooling and lubrication drill bit tips and cleaning stone chips in the well bottom with drilling liquid in the working conditions of high pressure, vibration, sand and slurry impacting during oil and natural gas prospecting.

Main Products

Cross groove thread nozzles, plum blossom type thread nozzles, outer hexagonal thread nozzles, internal hexagonal thread nozzles, Y type(three grooves) thread nozzles, gear wheel drill bit nozzles and press fracturing nozzles, there are various sizes and types of the products. We can recommend, design, develop, produce and supply the products according to the drawings and requirements of the customers.

Our Advantages:

Experienced with high producing technology and facilities

Varying sizes and customized needs available

Quality and quantity assured

Factory direct price

Trial order accepte

Product display

Common alloy grates,ghysical mechanical properties and recommended application

Common Alloy Grades, Ghysical Mechanical Properties And Recommended Application
Grade	WC%	Co/Ni %	Physical and mechanical properties			Grain size (μm)	Recommended application
Grade	WC%	Co/Ni %	Density (g/cm3)	TRS (N/mm²)	Hardness (HRA)	Grain size (μm)	Recommended application
ZG01	100	0	15.3-15.5	1200	95.5	0.3	Ultra-high hardness, high wear resistance, anti-corrosion, with certain anti-destructive ability
ZG04X	96	4	15.0-15.2	1600	92.8	0.8-1.0	Suitable for drawing die, non-ferrous metal wire drawing and wear-resistant parts
ZG06	94	6	14.8-15.1	2500	90.0	1.2	Good abrasion resistance, good compression resistance, suitable for wear-resistant parts that resist abrasion and high pressure.
ZG06X	94	6	14.8-15.1	2400	91.5	1.0	Superio wear resistance,good comprehensive properties,suitable for making non-standard structure components with higher wear resistance.
ZG06A	94	6	14.8-15.1	2150	92.5	0.6-0.8
ZG08	92	8	14.6-14.9	2700	89.0	1.2-1.6	Good general performance, used for general wear parts, molds, general tools, etc.
ZG10.2	90	10	14.3-14.6	3800	91.7	0.7	Good general performance, suitable for casing and oil nozzle products
ZG11	89	11	14.3-14.7	2800	88.5	1.2-1.6	Anti-wear, anti-erosion, good comprehensive mechanical strength, suitable for wear-resistant parts in the petroleum, chemical and mechanical industries.
ZG12X	88	12	14.2-14.5	3000	89.5	1.0-1.2	Anti-erosion, good comprehensive mechanical strength, suitable for impact-resistant wear-resistant parts, molds, and roller rings.
ZG15	85	15	13.8-14.2	3000	86.5	1.2-1.6
ZG15X	85	15	13.8-14.2	4500	89.0	0.7	Excellent wear resistance and toughness,it is suitable for making integral stamping dies, anti-vibration toolholders, etc.
ZG20	80	20	13.4-13.8	3100	85.0	1.0	Excellent wear resistance and toughness
ZN06	94	6	14.5-14.9	2000	90.0	1.2	Non-magnetic alloy, suitable for sealing ring, non-magnetic wear-resistant parts and corrosion-resistant parts.
ZN09	91	9	14.3-14.6	2300	89.0	1.2-1.6
ZN11	89	11	14.0-14.3	2600	88.0	1.2
